2 Ton Outdoor All Terrain Electric Stacker
Heavy-Duty Electric All Terrain Stacker for Outdoor Material Handling with 4500mm Lift Height and 2 Ton Capacity
Powerful 2 Ton Lifting Capacity
Designed to safely lift and transport loads up to 2 Ton, making it suitable for warehouses, farms, construction sites, factories, and outdoor logistics operations.
All Terrain Outdoor Performance
Large off-road drive wheels provide excellent traction and stability on gravel, dirt roads, uneven ground, and other challenging outdoor environments.
Electric Driving & Lifting
Powered by efficient electric drive and lifting motors for smooth operation, reduced labor intensity, and zero exhaust emissions.
High Lift Capability
Standard lifting height reaches 4500mm, with customized lifting heights available for different storage and handling requirements.
Wide Adjustable Support Legs
1200mm inner leg width accommodates various pallet sizes while improving machine stability during lifting operations.
Durable Heavy-Duty Construction
Reinforced steel frame and heavy-duty mast provide reliable performance for continuous industrial use.
Easy Operation
Ergonomic controls offer precise lifting, lowering, and driving functions, improving operator comfort and working efficiency.
- Overview
- Recommended Products
Technical Specifications
| Product Name | Outdoor All Terrain Electric Stacker |
| Rated Capacity | 2 Ton |
| Operation Type | Electric Driving & Lifting |
| Overall Dimensions | 2360 × 1450 × 2150 mm |
| Overall Height | 2360 mm |
| Overall Width | 1450 mm |
| Overall Length | 2150 mm |
| Maximum Lift Height | 4500 mm (Customizable) |
| Fork Length | 1070 mm |
| Inner Leg Width | 1200 mm |
| Power System | |
| Drive Motor | 48V / 2000W |
| Lift Motor | 48V / 3000W |
| Wheel Configuration | |
| Drive Wheel Size | Φ300 × 100 mm |
| Load Wheel Size | Φ300 × 80 mm |
Product Description
The 2 Ton Outdoor All Terrain Electric Stacker is engineered for heavy-duty material handling in demanding outdoor environments. Designed with a robust chassis and large all-terrain wheels, it delivers outstanding mobility on gravel roads, construction sites, farms, warehouses, and uneven working surfaces while maintaining excellent stability during lifting operations.
Featuring a 2 Ton rated lifting capacity and a maximum lift height of 4500mm, this electric stacker efficiently handles palletized goods, building materials, agricultural products, and industrial cargo. The lifting height can also be customized to meet specific application requirements.
Powered by a 48V 2000W drive motor and a 48V 3000W lifting motor, the machine provides smooth driving performance, powerful lifting capability, and energy-efficient operation. The 1200mm inner leg width allows compatibility with a wide range of pallet sizes while improving overall lifting stability.
Built with a heavy-duty steel frame and durable mast structure, the Outdoor All Terrain Electric Stacker offers reliable performance, low maintenance requirements, and high productivity, making it an ideal solution for construction companies, agricultural operations, logistics centers, manufacturing facilities, and outdoor material handling applications.
