2.5Ton Electric Lift Forklift Pure Copper Motor for Long Shift Work
2.5Ton electric lift forklift with pure copper motor and high-quality lithium battery. Long range, low heat, overcurrent protection. Limited stock – request your quote today!
- Overview
- Recommended Products
| Electric Motor | |
| Battery Model | Chilwee |
| Engine Type | AC Hoist Motor |
| AC Traction Motor | |
| Rated Power | 7.5KW |
| 7.5KW | |
| ChargerInputVoltage: | 220V |
| Charging Time: | 8-10h |
| Rated Voltage: | 60V |
| Number of batteries： | 10 |
| Airframe | |
| OverallMachineWeight (kg)inStandardUnloaded Condition | 3200 |
| Maxloading weight | 2500 |
| Dimension | 3520 |
| OverallLength(excluding forks) (mm): | 2450 |
| Overall Width (mm): | 1200 |
| Free Lift Height: | 2100 |
| Overhead Guard Height: | 2080 |
| MaximumOperatingHeight: | 3750 |
| Wheelbase: | 1620 |
| Gantry Crane: | 120 H-Type |
| Maximum Lifting Height (Unloaded): | 3000 |
| MastTilt(Forward/Backward): | 5°/13° |
| Walk | |
| Maximum Lifting Speed (No Load) (Adjustable) (mm/s): | 140 |
| Maximum Lifting Speed (Full Load) (Adjustable) (mm/s): | 160 |
| Maximum No-Load Operating Speed(Adjustable) (km/h): | 14 |
| Maximum Operating Speed (Fully Loaded) (Adjustable) (km/h): | 12 |
| Maximum Gradeability (Fully Loaded) (%): | 15 |
| MaximumGradeability (Unloaded) (%) | 20 |
| Load Center Distance (mm): | 500 |
| Row-based Steering: | Hydraulic Power Assist |
| Drive Axle: | 256-100 Cast Steel Heavy-Duty Type |
| Transition Bridge | 920-220 Integrated Suspension Cast Steel Heavy-Duty Type |
| Lighting System: | LED |
| Four-Wheel Drive: | Solid Tires |
| Tire model: |
Front: 650-10 Rear: 500-8 |
Product Description
The electric lift forklift is becoming the preferred equipment for warehouses, logistics centers, farms, and factories. This 2.5-ton electric lift forklift features a pure copper motor, delivering strong power, long service life, and low heat generation – ensuring continuous operation without overheating. Paired with a high-quality lithium battery, it offers long range and extended charge cycle life, with multiple intelligent protections including overcurrent and overvoltage protection.
Easy operation is another major advantage of this electric lift forklift. Users can learn basic operations in just 10 minutes, significantly reducing training costs. The comfortable seat comes with a seatbelt, and the spacious design reduces operator fatigue during long shifts. The seat is also adjustable forward and backward, allowing each driver to find their most comfortable position.
In terms of rough terrain capability, this electric lift forklift performs exceptionally well. It has strong climbing ability, easily handling slopes exceeding 30 percent gradient – ideal for hillside farms, ramped warehouses, and other challenging locations. Durable solid rubber tires are anti-slip and long-lasting, adapting to concrete, epoxy, and outdoor paved surfaces.
This electric lift forklift comes standard with a side-shift function and hydraulic lift system. The side-shift mechanism allows left and right fork movement without repositioning the truck, greatly improving loading and unloading efficiency. The hydraulic lift provides quick lifting with effortless pulling force. Paired with thickened manganese steel forks, loading and unloading require less effort. The wide-angle mast frame with reinforced multi-plate chain, plus thickened front and top beams, ensures safer loading.
For safety and stability, this electric lift forklift features a reinforced frame and thickened front forks for greater structural stability. The new large-screen LED dashboard offers clear, easy viewing with intuitive data reading for an excellent human-machine interaction experience. Low noise and zero emission make this electric lift forklift particularly suitable for farms, warehouses, factories, logistics centers, and supermarkets – both indoor and outdoor.
Additionally, this electric lift forklift supports custom body color and logo printing to match your brand image. We offer multiple electric forklift models for your selection. If you are interested, please click the link to contact us.
Advantages
1. High Efficiency, Low Noise & Zero Emission
Powered by electric drive with zero tailpipe emissions, meeting environmental standards. Significantly lower noise than diesel forklifts, ideal for indoor warehouses and nighttime operations.
2. Easy Maintenance & Quick Refueling
Simpler electric structure means fewer daily maintenance items, reducing downtime and service costs. Supports quick refueling for continuous high-efficiency handling.
3. Flexible Customization
Customizable models, body colors, logos, and optional configurations available. Contact customer service for exclusive color customization to match your brand or specific working conditions.
4. Hydraulic Lift + Adjustable Up/Down + Smooth Operation
Features a hydraulic lift system with vertically adjustable forks, delivering jerk-free lifting and lowering. Perfect for multi-tier racking and precision cargo handling.
