2Ton Electric Forklift Hydraulic Lift Adjustable for Warehouse Stacking
2Ton Electric Forklift with hydraulic lift system, adjustable up and down, smooth lowering and lifting for precise handling. Ideal for warehouses. Request a quote today!
- Overview
- Recommended Products
| Technical Parameter | |
| Maximum Lifting Capacity | 2000 kg |
| Length (excluding forks) | 2.4 m |
| Width | 1.2 m |
| Height | 2.1 m |
| Self Weight (unladen) | 2550 kg |
| Lifting Height | 3 m (customizable) |
| Chassis Material | Reinforced heavy-duty steel chassis, C-section steel 120 |
| Electrical System | |
| Drive Motor | 4000 W dual AC motors |
| Voltage | 60 V (adjustable based on working hours) |
| Wiring | Main cables: 25 mm² national standard |
| Battery | 5 x 70 Ah dry-cell batteries (adjustable based on working hours) |
| Lighting & Signals | LED headlight, left/right turn signals, brake light, driving light, instrument panel, electric horn, seat belt, etc. |
| Chassis System | |
| Front Axle | Cast steel front axle |
| Tires | Front: 650-10 (solid tires); Rear: 500-8 (solid tires) |
| Rear Axle | Cast steel rear axle |
| Braking System | Hand brake, hydraulic oil brake |
| Other Configurations | |
| Lift Cylinder | Reinforced sealed dual cylinders, genuine Tongheli parts, lifetime leak-proof guarantee |
| Fork Length | 1.07 m forged forks |
| Fork Dimensions | 1070 × 120 × 40 mm |
| Mast Material | Reinforced heavy-duty Laigang steel, thickness 20–30 mm |
| Chain / Sprocket | Multi-leaf chain with high load capacity; sprocket shaft uses 40 mm diameter heavy-duty sprocket |
| Steering Type | Hydraulic power steering |
| Turning Radius | 180° zero-turn (in-place steering) |
| Charging Time | 6–7 hours (220 V) |
| Operating Time | 4–8 hours |
| Climbing Angle | 15° |
| Included in Shipment | Auto-shutoff battery charger |
Product Description
The electric forklift is rapidly becoming the backbone of modern warehousing and logistics. This electric forklift features a detailed hydraulic lift system with an adjustable up and down mechanism, ensuring smooth lifting and lowering in daily operations.
Unlike conventional machines, this electric forklift uses a high-grade hydraulic cylinder to eliminate jerky movements. Whether you are working with multi-tier racking or frequently changing lift heights, this electric forklift allows you to adjust the fork height precisely via its up/down adjustable design.
Compared to internal combustion models, this electric forklift produces zero emissions and significantly less noise. The hydraulic lift system gives operators superior control, allowing them to stop at any height with confidence. Every electric forklift is factory-tested for hydraulic durability, ensuring no oil leakage or creeping over time.
In warehouse applications, the smooth lifting and lowering of this electric forklift reduce product damage substantially. The adjustable up and down feature means operators can stack pallets at different levels without repositioning the truck repeatedly. Moreover, this electric forklift includes overload protection – when the load exceeds capacity, the hydraulic system automatically limits lifting to protect both the operator and the machine.
Tiantong Machinery offers a full hydraulic warranty for this electric forklift. From light-duty assembly lines to heavy-duty storage facilities, this electric forklift combines hydraulic lift performance with vertical adjustability to boost your daily handling efficiency. If you are looking for a reliable, flexible, and eco-friendly electric forklift, this model deserves your first consideration.
Advantages
1. High Efficiency, Low Noise & Zero Emission
Powered by electric drive with zero tailpipe emissions, meeting environmental standards. Significantly lower noise than diesel forklifts, ideal for indoor warehouses and nighttime operations.
2. Easy Maintenance & Quick Refueling
Simpler electric structure means fewer daily maintenance items, reducing downtime and service costs. Supports quick refueling for continuous high-efficiency handling.
3. Flexible Customization
Customizable models, body colors, logos, and optional configurations available. Contact customer service for exclusive color customization to match your brand or specific working conditions.
4. Hydraulic Lift + Adjustable Up/Down + Smooth Operation
Features a hydraulic lift system with vertically adjustable forks, delivering jerk-free lifting and lowering. Perfect for multi-tier racking and precision cargo handling.
