3 Ton Economy Electric Pallet Truck
Compact 3 Ton Fully Electric Pallet Truck with Removable Battery Box for Warehouse Material Handling
3 Ton Load Capacity
Designed to transport heavy palletized goods efficiently in warehouses, factories, logistics centers, and distribution facilities.
Fully Electric Operation
Electric driving and electric lifting minimize operator effort while improving handling efficiency.
Compact Chassis
The compact body design allows smooth operation in narrow aisles and confined working environments.
Removable Battery Box
The detachable battery box enables convenient charging, battery replacement, and simplified maintenance.
Durable Steel Forks
High-strength steel forks provide excellent load-bearing performance and long service life.
Stable Power System
Equipped with a 48V 1500W drive motor and a 48V 1200W lifting motor for reliable daily operation.
Multiple Fork Width Options
Available with 550 mm and 685 mm fork widths to accommodate different pallet standards.
Low Maintenance Design
Simple mechanical structure and reliable electrical components reduce maintenance costs and downtime.
- Overview
- Recommended Products
Technical Specifications
| Rated Capacity | 3 Ton |
| Overall Dimensions | 1670 × 685 × 1260 mm |
| Fork Dimensions | 1160 × 160 × 50 mm |
| Fork Length | 1160 mm |
| Fork Outside Width | 550 / 685 mm |
| Fork Inside Width | 230 / 365 mm |
| Lifting Method | Electric Lifting |
| Power System | |
| Drive Motor | 48V 1500W |
| Lifting Motor | 48V 1200W |
| Wheel Configuration | |
| Drive Wheel | Φ160 × 55 mm |
| Load Wheel | Φ80 × 70 mm |
Product Description
The 3 Ton Economy Electric Pallet Truck is designed for efficient pallet transportation in warehouses, manufacturing plants, logistics centers, supermarkets, and other material handling environments. With a rated load capacity of 3 Ton, it provides reliable performance for daily pallet moving tasks while improving operational efficiency.
Powered by a 48V 1500W drive motor and a 48V 1200W electric lifting motor, the pallet truck delivers smooth traveling and stable lifting performance. The compact chassis allows operators to maneuver easily through narrow aisles, while the 1160 mm forks are suitable for most standard pallets. Multiple fork width options of 550 mm and 685 mm offer greater flexibility for different handling requirements.
Featuring a removable battery box for convenient charging and maintenance, durable steel forks, and a robust drive system, this electric pallet truck combines productivity, durability, and low operating costs. It is an ideal material handling solution for warehouses, distribution centers, factories, and retail storage facilities seeking dependable electric pallet transportation.
