1.5 Ton Electric Three Wheel Counterbalance Forklift
Compact 1.5 Ton Three Wheel Electric Forklift for Warehouse and Industrial Material Handling
Compact Three-Wheel Design
The three-wheel structure provides excellent maneuverability and a small turning radius, making it ideal for narrow aisles, warehouses, workshops, and confined working areas.
Fully Electric Drive System
Powered by a 48V electric system, this forklift delivers quiet, emission-free operation with lower maintenance requirements compared with traditional fuel-powered forklifts.
1.5 Ton Load Capacity
With a rated load capacity of 1.5 Ton and a 500mm load center distance, it provides reliable lifting performance for daily material handling applications.
Stand-On Operation Design
The stand-on driving configuration improves operator visibility, enhances flexibility, and allows quick entry and exit during frequent handling operations.
Stable Counterbalance Structure
The counterbalance design ensures excellent stability during lifting and transportation, improving safety and operational efficiency.
Efficient Lifting Performance
Equipped with a 1500W lifting motor and a maximum lifting height of 3000mm, it meets common warehouse stacking and loading requirements.
Solid Rubber Tires
Front and rear solid rubber tires provide durability, puncture resistance, and stable operation on indoor concrete floors.
Electronic Braking System
The electronic braking system offers smooth stopping performance and improves operational safety.
- Overview
- Recommended Products
Technical Specifications
| Product Name | 1.5 Ton Electric Three Wheel Counterbalance Forklift |
| Rated Load Capacity | 1.5 Ton |
| Load Center Distance | 500 mm |
| Operation Type | Fully Electric Stand-On Type |
| Battery Voltage | 48V |
| Overall Length (Without Fork) | 2140 mm |
| Overall Width (Without Fork) | 1045 mm |
| Overall Height (Static) | 2055 mm |
| Fork Length | 1070 mm |
| Fork Thickness | 40 mm |
| Maximum Lifting Height | 3000 mm |
| Minimum Fork Height | 100 mm |
| Front Tire | Φ500 × 100 Solid Rubber Tire |
| Rear Tire | Φ300 × 100 Solid Rubber Tire |
| Drive Motor Power | 2200W |
| Lifting Motor Power | 1500W |
| Mast Tilt Angle | 6° |
| Braking System | Electronic Braking |
| Vehicle Dimensions | |
| Vehicle Height | 2055 mm |
| Vehicle Length | 1740 mm |
| Rear / Pedal Length | 400 mm |
Product Description
The 1.5 Ton Electric Three Wheel Counterbalance Forklift is designed for efficient material handling in warehouses, factories, logistics centers, and industrial facilities. With a rated load capacity of 1.5 Ton and a 500mm load center, it provides reliable lifting performance for daily loading, stacking, and transportation operations.
Featuring a compact three-wheel counterbalance structure, this electric forklift offers excellent maneuverability and a small turning radius, making it suitable for narrow aisles and limited working spaces. The stand-on operation design improves operator visibility and allows flexible handling during intensive working conditions.
Powered by a 48V electric system, the forklift delivers quiet, zero-emission operation with low maintenance requirements. Equipped with a 2200W drive motor and 1500W lifting motor, it provides smooth driving performance and stable lifting capability with a maximum lifting height of 3000mm.
Built with durable solid rubber tires, electronic braking system, and a stable counterbalance design, the 1.5 Ton Electric Three Wheel Forklift is an ideal solution for modern warehouse material handling and industrial transportation applications.
