1.5 Ton Outdoor Electric Rough Terrain Stacker
Built for outdoor material handling on rough terrain, this all-electric rough terrain stacker features large off-road wheels, a 1.5 Ton lifting capacity, and a maximum lift height of 4500mm, making it ideal for farms, construction sites, warehouses, logistics yards, and uneven working environments.
Designed for Rough Terrain
Large-diameter off-road wheels provide excellent traction and stability on gravel, dirt roads, construction sites, and other uneven surfaces.
1.5 Ton Heavy Duty Capacity
Capable of handling pallets, construction materials, agricultural products, and industrial goods with reliable lifting performance.
Fully Electric Drive & Lift
Powered by separate drive and lift motors for smooth, efficient, and low-maintenance operation without engine emissions.
4500mm Maximum Lift Height
Standard lifting height reaches 4500mm and can be customized to meet different warehouse and outdoor stacking requirements.
Wide Straddle Legs
1200mm inner leg width accommodates various pallet sizes while providing improved stability during lifting.
Powerful 48V Electric System
Equipped with a 48V 1500W drive motor and 48V 2200W lifting motor for reliable performance and continuous operation.
Durable Steel Construction
Heavy-duty frame and reinforced mast ensure long service life in demanding industrial and outdoor environments.
Suitable for Multiple Industries
Ideal for construction, agriculture, warehouses, logistics centers, factories, and outdoor material handling operations.
- Overview
- Recommended Products
Technical Specifications
| Product Name | Outdoor Electric Rough Terrain Stacker |
| Load Capacity | 1.5 Ton |
| Operation Type | Electric Lift |
| Overall Dimensions (L × W × H) | 2150 × 1450 × 2360 mm |
| Overall Height | 2360 mm |
| Overall Width | 1450 mm |
| Overall Length | 2150 mm |
| Maximum Lift Height | 4500 mm (Customizable) |
| Fork Length | 1070 mm |
| Inner Leg Width | 1200 mm |
| Electric Power System | |
| Drive Motor | 48V 1500W |
| Lift Motor | 48V 2200W |
| Wheel Configuration | |
| Drive Wheel | Φ300 × 100 mm |
| Load Wheel | Φ300 × 80 mm |
Product Description
The 1.5 Ton Outdoor Electric Rough Terrain Stacker is specially designed for lifting and transporting palletized materials in outdoor and uneven working environments. Featuring a robust chassis, large off-road wheels, and a fully electric drive system, it delivers reliable handling performance for construction sites, farms, logistics yards, warehouses, and industrial facilities.
With a rated load capacity of 1.5 Ton and a maximum lifting height of 4500mm, this electric stacker efficiently handles high stacking operations while maintaining excellent stability. The 1200mm wide straddle legs accommodate various pallet sizes, and the 1070mm forks are suitable for standard pallet handling applications. Customized lifting heights are also available to meet different operational requirements.
Powered by a 48V 1500W drive motor and a 48V 2200W lifting motor, the machine provides smooth travel, efficient lifting, and low maintenance operation without exhaust emissions. Its rugged steel construction and rough terrain wheel configuration make it an ideal material handling solution for demanding outdoor applications where conventional electric stackers cannot operate effectively.
