2 Ton Counterbalance Electric Stacker
Heavy-Duty Counterbalance Electric Stacker with 4000mm Lift Height for Pallet Handling Without Support Legs
Counterbalance Design Without Support Legs
The counterweight structure allows direct handling of closed pallets and various non-standard pallets without front support legs, providing greater flexibility in warehouses and industrial facilities.
2 Ton Load Capacity
Designed to safely handle loads up to 2000kg, making it suitable for heavy-duty material handling applications.
4000mm Maximum Lift Height
Provides efficient vertical stacking and storage while maximizing warehouse space utilization.
Full Electric Ride-On Operation
Electric driving, lifting, and lowering reduce operator fatigue while improving productivity during long working shifts.
Powerful Drive & Lift Motors
Equipped with a 3000W drive motor and 2000W lifting motor for smooth acceleration, stable lifting performance, and reliable operation.
Electronic Braking System
Responsive electronic braking improves operational safety while reducing maintenance requirements compared with mechanical brake systems.
- Overview
- Recommended Products
Technical Specifications
| Product Name | Counterbalance Electric Stacker |
| Rated Capacity | 2 Ton |
| Load Center | 500 mm |
| Operation Type | Full Electric Ride-On |
| Overall Length (Without Forks) | 2430 mm |
| Overall Width | 1023 mm |
| Overall Height (Mast Lowered) | 2566 mm |
| Fork Length | 1070 mm |
| Fork Thickness | 30 mm |
| Maximum Lift Height | 4000 mm |
| Minimum Fork Height | 30 mm |
| Power System | |
| Battery Voltage | 48V |
| Drive Motor | 3000 W |
| Lift Motor | 2000 W |
| Drive Wheel | Φ170 × 55 mm |
| Front Wheel | Φ200 × 70 mm |
| Rear Wheel | Φ100 × 40 mm |
| Brake System | Electronic Brake |
Product Description
The 2 Ton Counterbalance Electric Stacker is designed for efficient pallet handling and stacking in warehouses, manufacturing plants, logistics centers, and distribution facilities. With a rated load capacity of 2000kg and a maximum lifting height of 4000mm, it provides reliable performance for demanding material handling applications.
Featuring a counterbalance structure without front support legs, the stacker can easily handle closed pallets, enclosed-bottom pallets, and a wider variety of cargo types that conventional straddle stackers cannot accommodate. The full electric ride-on design delivers smooth driving, lifting, and lowering operations while significantly improving operator comfort and working efficiency.
Powered by a 3000W drive motor, a 2000W lifting motor, and a dependable 48V battery system, the machine offers stable lifting performance, responsive travel, and excellent durability. Combined with an electronic braking system and compact counterbalance design, it is an ideal solution for high-density warehouse storage, logistics operations, and industrial material transportation.
